| Dimension: | Dia 3mm, 4mm, till 25mm with length 5mm, 8mm, 10mm, till 330mm, cut to length |
| Cutting amgles: | 30°, 45°, 60°, 90°, 120°. Or Based On Requirement |
| Material: | 100% virgin tungsten carbide steel |
| Grade: | YL10.2 |
| Hardness: | HRA92 |
| Composition: | 10%Co+90%WC |
| Grain Size: | 0.6um |
| Surface: | unground |
| Features: | durable,high pwear resistance,Replaceable,Very Sharp Point,Create Fine Edge |
| Application: | Assembling On Tool Bit, Engraving or Scribing On Very Hard Items, For Example: Aluminum, Brass, Bronze, Metals, Steel, Glass, Ceramics, Hardwood, Etcs. |
| D(mm) | L(mm) | α |
| 1.5 | 5 | 30°-110° |
| 2 | 10 | 30°-110° |
| 2.5 | 10 | 30°-110° |
| 3 | 18 | 30°-110° |
| 3 | 10 | 30°-110° |
| 3.5 | 10 | 30°-110° |
| 4 | 20 | 30°-110° |
| Other size can be customized | ||
Assembling On Tool Bit, Engraving or Scribing On Very Hard Items, For Example: Aluminum, Brass, Bronze, Metals, Steel, Glass, Ceramics, Hardwood, Etcs.Your enquiry with customized request is more than welcome here !
1. un-gound, finish-ground in metric and imperial diameters;
2. Carbide rods with central coolant duct;
3. Fixed length Carbide Rod
4. Random Length carbide rod
5. Carbide rods with chamfered end.
